Fine Adjust Applicator for Sabre? Flat Blade Crimp Terminal
PARTS LIST
FineAdjust Applicator 63901-2600
Item
Order No
Engineering No.
Description
Quantity
Perishable Tooling
63901-2670 63901-2670 Tool Kit (All “Y” Items) REF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
63444-2025 63444-2025 Conductor Punch 1 Y
63445-2055 63445-2055 Conductor Anvil 1 Y
63446-3231 63446-3231 Insulation Punch 1 Y
63445-3250 63445-3250 Insulation Anvil 1 Y
63443-0035 63443-0035 Cut-Off Plunger 1 Y
63443-0036 63443-0036 Front Plunger Retainer 1 Y
Other Components
11-18-4083 60707-8 Feed Guide 1
63443-0009 63443-0009 Scrape Chute 1
63443-0024 63443-0024 Key 1
63443-0090 63443-0090 Wire Stop 1
63443-1719 63443-1719 18.90mm Spacer 1
63443-2215 63443-2215 15.00mm Spacer 1
63443-2302 63443-2302 3.10mm Spacer 1
63443-2801 63443-2801 Front Plunger Striker 1
63443-2913 63443-2913 Wire Hold Down Plunger 1
63443-6121 63443-6121 Rear Cover 1
63600-1057 63600-1057 Striker Plunger Spring 1
63700-0539 63700-0539 Cut-off Plunger Spring 1
Frame
63800-4901 63800-4901 Top 1
63801-3281 63801-3281 Base 1
63801-4650 63801-4650 Track 1
Hardware
N/A N/A M3 by 6 Long SHCS 2**
N/A N/A M3 by 6 Long FHCS 1**
N/A N/A M4 by 6 Long SHCS 2**
N/A N/A M4 by 12 Long BHCS 2**
N/A N/A M4 by 50 Long SHCS 2**
N/A N/A M5 by 12 Long SHCS 1**
N/A N/A #10-32 by 3/8”Long Flat Point SSS 1**
N/A N/A #10-32 Hex Jam Nut 1**
** Available from an industrial supply company such as MSC (1-800-645-7270).
Doc No. ATS-639012600
Revision: B
Release Date: 07-08-09
Revision Date: 01-26-10
UNCONTROLLED COPY
Page 3 of 5
